SKU: H2BT

H2BT- HEAD UNIT | Bluetooth, MP3, Dual USB, AM/FM Radio, Pre Amp

Sale price$ 159.99 Regular price$ 199.99
Sold out

The H2BT was created to deliver powerful clean signal to your amplifiers with all the modern features required for streaming and tuning. Easy to use controls with a common sense layout will ensure that you get the most out of your audio experience.

The USB, SD, and BT readers that are used for streaming or using up to 64GB flash drives. AM/FM stations have 18 memory locations.

This CD-less single din, produces 50 watts per channel while the pre-amp output is adjustable up to 5v with a subwoofer output. This is essential for high performance, optimizing your amplifiers for outstanding sound quality and high SPL.

Change your style on demand with an array of color presets via the backlit RGB buttons without effecting the main white display.  The two band equalizer allows you to adjust functions such as master level, bass, treble, balance, fade, and subwoofer controls easily. Connect to your USB via two USB ports which both have charging capability. Also onboard is a front facing AUX input jack.

  • Non CD, Mech-less Single Din USB/BT Receiver
  • USB, SD, BT Reader / Streamer
  • MP3, WMA, FLAC, MAV
  • AM/FM Radio
  • 30 Memory Locations
  • Remote control
  • RGB: 7 Selectable Colors
  • Speaker Impedance: 4 Ohm
  • Display: 3" VA White Backlit
  • Pre-Outputs: 3 Pair (Front, Rear, Sub)
  • Power: 50 x 4 Watts Max
  • Equalizer: 2 Bands with Adjustable Bass, Treble, and Subwoofer
  • Pre-amp output: 5v + Subwoofer Output
  • Inputs: USB, SD, BT, Front AUX
  • Mounting Dims: 7"(W) x 2"(H) x 3-7/8"(D)
Rated power source 14.4V DC (11V to 16V operation)
Maximum Current Consumption 10 Amp
Dimensions (W x H x D): Chassis 178mm x 50mm x 150mm
Bezel frame 188mm x 58mm x 30mm
Weight 15.9 Oz / 452 grams


Screen Size 3” / 75 x 25mm
Display Type VA LCD
Temperature Operation -20°C to +60°C (14°F to 140°F)
Frequency Range FM: 87.5 ~ 107.9 KHz
Presets Memory 18 Stations
Region North America “USA”
Sensitivity Adjustment LOC / DX & ST / Mono
Sensitivity <20dB
Stereo Separation >25dB
Maximum Power Output 50W X 4 Ch @ 4 ohm (14.4v)
Continuous Power Output 17W x 4 Ch @ 4 ohm (14.4v)
Pre-output Level 5 Volts (14.4V)
Equalizer 2 bands (Bass: 60Hz, Treble: 10KHz)
Gain +/- 7dB
Preset EQ Jazz / Rock / Pop / Classic
Audio Control Volume / Balance / Fader / Loudness / Bass / Treble
Subwoofer Control Vol (0-20) / Cut (80/120/160 Hz)
Signal to Noise Ratio >60dB
THD <0.3%
Frequency Response 20Hz – 20Khz
Bluetooth Version / Services V4.1 / Audio Streaming / Hands Free calls
Audio Protocol A2DP v1.2 Sink (SNK)
Aux input Front 3.5mm Jack Stereo Audio
Microphone Built-In Microphone on faceplate
Remote Control Frontal IR Receptor
Type/Class V1.1 / V2.0 / MSC / MTP / FAT16 / FAT32 / NTFS
Format Files Supported MP3, WMA, FLAC, MAV
Info Display Format ID3 Tag
Memory Size Reader up to 64 Gb
Max Current Supply 1.5 Amp (Charging USB port)
Number of USB Ports 2 x Front (1 for Audio / 1 for Charging)
SD Slot 1 x Front Micro SD
