SKU: DSP-1

DSP-1 - Digital Signal Processor Built-In 4 Channel Amplifier

Sale price$ 279.99

*BY PURCHASING THIS HIGH  PERFORMANCE PRODUCT YOU AGREE TO THE TERMS AND CONDITIONS SET FORTH IN THE LIMITED WARRANTY EXCLUSION POLICY

CLICK HERE FOR THE DSP-1 SOFTWARE DOWNLOAD

The DSP-1 is a unique combination of a Four Channel amplifier and a Digital Signal Processor in one piece. We have used uncompromising design and engineering that Massive Audio customers are accustomed to, incorporating the latest in small format technology. Not only do you get a high performance, high quality product, but you also are saving a lot of space. The same proven quality of Massive Audio lives on in the new DSP-1.

  • Eight (8) fully configurable output channels capable of 4V rms (12.5V pp) RCA output
  • Eight (8) summing input channels, compatible with Low-Level& High-Level input types
  • Bluetooth Audio Streaming with Codec for audiophile audio quality
  • Elite Audio Reproduction from:
    a) 24-bit resolution ADC/DAC’s
    b) 56-bit double precision signal processing
    c) Frequency Response from 10hz to 20Khz (+/- 1dB)
    d) THD (Total Harmonic Distortion) < 0.05%
    e) SNR (Signal to Noise Ratio) > 95dB
  • Audio Sign Processor:
    a) Precision crossover system: Linkwitz-Riley &Butterworth topologies
    b) 12 / 18 / 24 / 36 / 48 dB octave crossover slopes available
    c) Full Pass / High Pass / Low Pass / Band Pass / Peak /Shelving Filters
    d) Up to 31 Parametric equalizer bands with adjustable frequency & bandwidth
    e) Full Time-Alignment correction & Phase rotation
    f) R.M.S. limiter with adjustable Threshold, Attack, & Decay



RMS Power 60w x 4
PEAK Power n/a
RMS @ 2 Ohms 80w x 4
Bridged RMS n/a
Min Impedance 2 Ohm
Min Ohm Bridged n/a
THD @ 4Ohm Load 30% Rated Power <0.05%
S/N >95 dB
Max Voltage 16v
Max RCA Voltage 8.5v (+/- 5%)
Freq. Response 10Hz ~ 20KHz
Dimensions 4.2 (in) W x 1.6 (in) H x 6.5 (in) L
Bass Remote n/a
